 Author |
 Le Mans 66 (currently 1 views) |
| Neil KilBane |
| Posted on: June 27th, 2009, 15:53:10 |
  |
|
Maximum Member2
just a little fine tuning left to do.
Location: Newtown Forbes, Ireland
Posts: 1,423
Reputation: 0 (tot: ) |
|
|
|
|
|
 |
| Tom Wiggers |
Posted on: September 15th, 2009, 18:35:41
 Attachment: mm66.jpg - 53.15 KB (1301 views) |
|
|
Big Member
youtube.com/profile_videos?user=marcosminigt
Location: Hengelo
Posts: 224
Reputation: 0 (tot: ) |
|
|
 Logged |
|
|
 |
Reply: 1 - 13 |
|
|
| Graham Bichard |
| Posted on: September 15th, 2009, 18:58:07 |
|
|
Maximum Member2
Posts: 752
|
|
Nice clip there Tom!
And weren't the cars more interesting to look at then? Not all aerodymanic aids and wings!
As for the Le Mans MM, does anyone have any specs on the car? Spec of the engine, final drive, wheel/tyre sizes etc? |
|
|
|
| |
Reply: 2 - 13 |
|
|
| Tom Wiggers |
| Posted on: September 15th, 2009, 20:52:58 |
|
|
Big Member
youtube.com/profile_videos?user=marcosminigt
Location: Hengelo
Posts: 224
Reputation: 0 (tot: ) |
|
car ran more than 200kmph on Mulsanne straight (I believe the 67 car ran 220kmph)
1275 engine (maybe 1293cc)
10" dunlops
I am still waiting for the ACO papers on the 66 car. |
|
| Logged |
|
|
| |
Reply: 3 - 13 |
|
|
| Neil KilBane |
| Posted on: September 15th, 2009, 23:20:09 |
|
|
Maximum Member2
just a little fine tuning left to do.
Location: Newtown Forbes, Ireland
Posts: 1,423
Reputation: 0 (tot: ) |
|
The 66 car ran an "off the shelf" 1293cc works customer spec rally prepared engine.
There are some great articles about the 66 race and the car in the main section of the MMOC website . |
|
|
|
|
| |
Reply: 4 - 13 |
|
|
| Graham Bichard |
| Posted on: September 16th, 2009, 14:19:22 |
|
|
Maximum Member2
Posts: 752
|
|
“ |
Quoted from Neil KilBane, posted September 15th, 2009, 23:20:09 at here |
” |
The 66 car ran an "off the shelf" 1293cc works customer spec rally prepared engine.
|
|
That's good going, but I wonder what it was revving to? What final drives were available in 66?
220kmh - whats that in real money? 135mph? |
|
|
|
| |
Reply: 5 - 13 |
|
|
| admin |
| Posted on: September 17th, 2009, 07:46:39 |
|
|
 Administrator
Location: Maidenhead, UK
Posts: 2,383
Reputation: 1 (tot: 1) |
|
| I think the '67 car was clocked at 141mph on the Mulsanne straight. I doubt if the engines would be revved above 6,500 for an endurance race in 1966, so that would imply a fairly tall final drive, possibly 2.9:1. The '67 engine would have been a full race engine, which broke because the oil pump drive pin sheared off. |
|
|
|
 |
Reply: 6 - 13 |
|
|
| Rodger Howard |
| Posted on: September 17th, 2009, 08:36:06 |
|
|
Medium Member
Location: Melbourne Australia
Posts: 162
Reputation: 0 (tot: ) |
|
| My understanding was that they put the largest crownwhhell they could fit in the housing. Would that mean that it was less than 2.9:1? |
|
|
|
| |
Reply: 7 - 13 |
|
|
| Tom Wiggers |
| Posted on: September 17th, 2009, 20:00:34 |
|
|
Big Member
youtube.com/profile_videos?user=marcosminigt
Location: Hengelo
Posts: 224
Reputation: 0 (tot: ) |
|
2.9:1 that would app be 19 mph per 1000 revs
If 6500 revs x 19 = ~123 mp/h top
|
|
| Logged |
|
|
| |
Reply: 8 - 13 |
|
|
| Tertius van Zyl |
| Posted on: September 18th, 2009, 09:11:53 |
|
|
Big Member
Location: Johannesburg South Africa
Posts: 289
Reputation: -1 (tot: -1) |
|
| I asked the current owner of the 67 car and he has confirmed that it had a 2.9 final drive for le Mans.. |
|
|
|
| |
Reply: 9 - 13 |
|
|
| Graham Bichard |
| Posted on: September 18th, 2009, 19:31:11 |
|
|
Maximum Member2
Posts: 752
|
|
19mph per 1000rpm. By my maths that would require 7400ish rpm to hit 141mph. I'm guessing it would be an all steel bottom end very carefully put together to last 24hrs!
(On a better note, the MPi does approx 22mph per 1000rpm, so I'd 'only' have to hit 6500rpm on the autobahn to do 140mph!  )
Were there any mechanical changes for the 67 car? |
|
|
|
| |
Reply: 10 - 13 |
|
|
| Lee Matthews |
| Posted on: March 20th, 2010, 20:26:00 |
|
|
Minimum Member
Location: South Gloucester
Posts: 69
|
|
|
|
|
| |
Reply: 11 - 13 |
|
|
| jimnaylor |
| Posted on: August 24th, 2011, 21:51:38 |
|
|
Big Member
Location: Bedfordshire
Posts: 222
|
|
|
|
|
| |
Reply: 12 - 13 |
|
|
| admin |
| Posted on: August 25th, 2011, 08:54:22 |
|
|
Administrator
Location: Maidenhead, UK
Posts: 2,383
Reputation: 1 (tot: 1) |
|
“ |
Quoted from Rodger Howard, posted September 17th, 2009, 08:36:06 at here |
” |
My understanding was that they put the largest crownwhhell they could fit in the housing. Would that mean that it was less than 2.9:1?
|
|
I only just noticed this. Of course you meant the largest pinion. You can get a 2.7:1 final drive into a Mini gearbox but with some machining to provide enough clearance for the pinion.
Btw it's well worth subscribing to the Maximum Mini mailing list which you can do via ether of the blogspot links above. |
|
|
|
| |
Reply: 13 - 13 |
|
|
|
